N2XSY

N2XSY 12/20KV XLPE/CTS/PVC

Construction:

• Conductor

Bare copper circular stranded,according to class 2 of IEC 60228

• Semiconducting layer

Extruded compoud

• Insulation

XLPE compound

• Metallic screen

Copper Tapes

• Sheath

PVC compound ST2 quality or LSOH thermoplastic compound ST8 quality

Applicable standards :

• IEC 60502-2    Design and tests guidelines
• IEC 60228       Conductors
• IEC 60332-1    Flame retardant
• IEC 60332-3 C Fire Retardant on bunched cables
• IEC 60754-1    Halogen free properties
• IEC 61034-1,2  Low smoke emission
